FASS Extended Length Extreme Water Separator

FASS XWS3002XL Extreme Water Separator | 2 Micron

The FASS XWS3002XL Extreme Water Separator is designed to provide advanced water separation and fuel filtration for compatible FASS diesel fuel systems. Featuring an improved filter element rated at 2 microns absolute, this upgraded water separator traps water within the filter media, eliminating the need for a traditional drain.

Designed to work exclusively with the FASS PF3001XL fuel filter, the XWS3002XL replaces previous-generation water separator designs. When upgrading from discontinued filter combinations, the XWS3002XL must be installed on the pressure side of the fuel system, while the PF3001XL is installed on the suction side.

Key Features

• Improved Extreme Water Separator design
• 2-micron absolute filtration rating
• Filter element traps water without requiring a drain
• Designed for use with the FASS PF3001XL fuel filter
• Installs on the pressure side of the fuel system
• Updated replacement for previous-generation FASS water separator filters

Benefits

The FASS Extreme Water Separator provides improved fuel filtration and water separation to help protect diesel fuel system components from contamination. Its updated filter media captures water without a manual drain, simplifying routine maintenance while supporting dependable fuel system operation.

Compatibility

The XWS3002XL must be used with the FASS PF3001XL fuel filter. These updated filters cannot be combined with discontinued FF-3003, FF-3010, FS-1001, or FS-1020 filters.

Installation Notes

• Install the XWS3002XL on the pressure side of the fuel system
• Install the PF3001XL on the suction side of the fuel system
• Both updated filters must be used together when replacing discontinued filter combinations

Important: The XWS3002XL and PF3001XL are designed to operate as a matched filter combination. Do not mix these filters with previous-generation FASS filters.
