Evolution CTS4 2020-2023 GM L5P Duramax

Edge Evolution CTS4 Performance Tuner & Monitor | 2020-2023 L5P Duramax

Unlock additional power, improved drivability, and advanced vehicle monitoring with the Edge Evolution CTS4 Performance Tuner & Monitor. Designed for 2020-2023 Chevrolet Silverado and GMC Sierra 2500HD/3500HD trucks equipped with the 6.6L L5P Duramax diesel engine, this next-generation tuning system delivers gains of up to 125 horsepower and 275 lb-ft of torque at the tires while providing optimized 10-speed transmission tuning and real-time vehicle monitoring.

The included Edge Locksmith tool enables in-vehicle ECM and TCM unlocking without removing the modules from the truck. Four pre-loaded performance levels allow drivers to select the appropriate calibration for daily driving, towing, or performance applications. Adjustable Throttle Boost further enhances accelerator response, while transmission calibrations optimize shift timing, shift feel, and power delivery for improved overall drivability.

Featuring a high-resolution 5.5" touchscreen, the CTS4 provides customizable digital gauges, data logging, diagnostic capabilities, and access to supported vehicle-specific functions. Monitor critical parameters such as boost, EGT, DPF soot level, regeneration history, and fluid temperatures while maintaining factory emissions equipment. Compatible Edge EAS sensors and camera accessories provide additional monitoring options.

Key Features

• Up to 125 horsepower and 275 lb-ft of torque gains at the tires
• Includes Edge Locksmith tool for in-vehicle ECM and TCM unlocking
• Four pre-loaded performance levels for different driving applications
• 10-speed Allison transmission tuning optimizes shift strategies and drivability
• Adjustable Throttle Boost for improved accelerator response
• Performance testing demonstrated quarter-mile improvements of up to 1.3 seconds and 8 MPH
• 5.5" high-resolution touchscreen with customizable digital gauges
• Real-time monitoring of supported engine, transmission, boost, EGT, DPF, and fluid temperature parameters
• Custom alerts, warnings, and vehicle data logging
• Read and clear supported Diagnostic Trouble Codes (DTCs)
• Manual DPF regeneration capability on supported applications
• Adjustable tire size calibration for 26"-38" tires
• Adjustable vehicle speed and engine RPM limiters
• Adjustable idle speed from 600-1,800 RPM
• Allison transmission relearn functionality
• Retains supported drive mode, exhaust brake, Tow/Haul, and grade braking settings
• Compatible with select Edge EAS sensors and backup camera accessories
• Emissions-friendly calibrations designed to retain factory emissions equipment

Performance Levels

• Economy: +50 HP / +100 lb-ft
• Towing: +75 HP / +160 lb-ft
• Performance: +90 HP / +180 lb-ft
• Extreme: +125 HP / +275 lb-ft

Benefits

The Edge Evolution CTS4 combines engine and transmission tuning to deliver stronger acceleration, improved throttle response, and optimized shifting across a variety of driving conditions. Multiple performance levels allow drivers to tailor power delivery for towing, hauling, daily driving, or maximum performance, while advanced monitoring and diagnostic features provide valuable insight into vehicle operation. Its emissions-friendly calibrations are designed to deliver improved performance without removing or disabling factory emissions equipment.

Fitment

Fits 2020-2023 Chevrolet Silverado 2500HD/3500HD and GMC Sierra 2500HD/3500HD trucks equipped with the 6.6L L5P Duramax diesel engine and Allison 10-speed automatic transmission.

What's Included

• Edge Evolution CTS4 Tuner & Monitor
• Edge Locksmith ECM/TCM Unlock Tool
• Four pre-loaded engine performance calibrations
• Compatible 10-speed transmission tuning calibrations

Important Notes

• A PC and Edge Update Agent software are required to complete the tuning process.
• Each device can unlock and tune only one vehicle.
• Once the ECM is unlocked and flashed, the vehicle can be returned to its factory calibration, but the ECM unlock process cannot be reversed.
• Devices become non-returnable once VIN locking and ECM/TCM unlocking are completed.
• Factory emissions equipment must remain installed and operational.
• Edge calibrations have passed in-house emissions testing; CARB Executive Order submissions are being processed. CARB approval should not be assumed until an applicable Executive Order is issued.
• Available parameters, functions, and accessories may vary by vehicle application.
