Fuel Pressure Relief Valve Shim Kit, LLY LBZ LMM | 2004.5-2010

Merchant Automotive

$7.99
SKU:
10269
Adding to cart… The item has been added

Merchant Automotive Fuel Pressure Relief Valve Shim Kit for 2004.5-2010 6.6L Duramax LLY, LBZ and LMM

This shim kit restores the opening pressure of the fuel rail pressure relief valve (PRV) on the LLY, LBZ and LMM Duramax. The shims fit behind the valve's internal spring and add preload, so the valve holds rail pressure instead of opening early and sending fuel back to the tank.

Key Features

  • (3) 4mm flat washer shims: most trucks use two, and some need all three
  • 20mm x 1.5 hex nut threads into the relief valve so it can be held in a vise while the cap is removed
  • Installs in the factory relief valve; no new valve required
  • 1-year warranty

Benefits

With age, the relief valve spring weakens and the valve can open under the high rail pressure the ECM commands at full throttle. Fuel escapes back to the tank, and the truck loses power and can set low rail pressure codes such as P0087 and P1093. Shimming the valve brings its opening pressure back up, so it can hold pressure during hard acceleration and towing. This fixes a weak relief valve for a few dollars, rather than replacing the valve.

Fitment

2004.5-2010 Chevrolet Silverado and GMC Sierra 2500HD and 3500 with the 6.6L Duramax LLY, LBZ or LMM. On these trucks, the relief valve sits on the driver's-side fuel rail near the firewall.

What's Included

  • (3) 4mm flat washer shims
  • (1) 20mm x 1.5 hex nut
