GM Driveshaft Slip Yoke Boot Kit, Duramax | 2003-2019

GM Driveshaft Slip Yoke Boot Kit, Duramax | 2003-2019

This is the genuine GM rubber boot kit (GM 12471527) that covers the slip yoke on the propeller shaft of Duramax-powered Chevrolet Silverado and GMC Sierra HD trucks. The boot seals the sliding spline joint, keeping road dirt and water out and grease in, so the slip yoke can move freely as the suspension travels. The kit comes with three clamps, so the boot can be installed without buying clamps separately.

Key Features

• GM part number 12471527 (formerly sold as ACDelco GM Original Equipment)
• Black rubber boot, original equipment specification
• Length: 3.2 in (79.00 mm)
• Wall thickness: 0.314 in (8.00 mm)
• Both ends: 1.65 in (42.00 mm) inside diameter, 2.26 in (57.50 mm) outside diameter
• Includes three clamps

Benefits

A torn or cracked slip yoke boot lets grit and water reach the splines and lets grease escape, which speeds up spline wear. Replace if worn or damaged, and check it whenever the driveshaft is removed for U-joint, slip yoke or transfer case work. Because the clamps come in the kit, the boot can be replaced in one trip.

Fitment

Fits 2003-2019 Chevrolet Silverado and GMC Sierra 2500HD and 3500 with the 6.6L Duramax diesel, covering the LB7, LLY, LBZ, LMM, LML and L5P engines.

What's Included

• (1) Driveshaft slip yoke boot
• (3) Clamps
